LE-04PRS

TYPE SERVO MOTOR DRIVE REEL TO REEL PRINTING MACHINE

SERIES SERVO TYPE  MEMORY MODULE TYPE SERVOMOTOR DRIVE 4 COLORS FLEXOGRAPHIC PRINTING MACHINE



performance and characteristics:

  1. 360º SERVOMOTOR continuous and adjustable longitudinal register device.
  2. TYPE SERVO MOTOR DRIVE REEL TO REEL PRINTING MACHINE
  3. Electric control by using PLC with full color touch-screen human machine interface.
  4. Use electronic type push-button device to adjust the registration with forward and backward adjustment.
  5. Line speed controlled by harmony synchronous driving syste
  6. automatic edge position control (EPC) on unwind.
  7. Easy operation flexible starting accurate color register.
  8. The meter counter can set printing quantity according to the requirements stop the machine automatically at the set quantity or when the material is cut off.
  9. Lift and lower the printing plate cylinder manually it will automatically stir the printing ink after lifting.
  10. Reliable drying system coordinated with high-speed rotation it will automatically break circuit when the machine stops.
  11. Current output type temperature control system makes heating quicker and electricity saving.
  12. The printing ink is spread by the knurled cylinder with even ink color.
  13. Obverse and reverse side once-through continuous printing.
  14. The frequency control of motor speed adapts to different printing speeds.
  15. There are inch&stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

MODEL

LE-04PRS

CHARACTERISTIC

AUTOMATIC FLEXOGRAPHIC COLOR PRINTING

APPLICABLE PLASTIC CLOTH

PP WOVEN BAG

PRODUCTION CAPACITY

80~120M/Minute

        PRINTING POSSIBILITY

       0+4 , 1+3 , 2+2 , 3+1

NO.OF COLOR

4 COLORS

PRINTING WIDTH

400MM~850 MM

PRINTING LENGTH

500-1200 MM



PRINTING

RUBBER PLATE , ZINE PLATE (7MM)

POWER

5HP

POWER COMSUMPTION

19.6KW

PRINTING INK

INK



MACHINE DIMENSION

L7800 x W1780 x H1750MM (N.W 7500KGS)

THE SPECIFICATIONS AND SIZES MENTIONED IN THIS LEAFLET ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE
