MODEL
|
LE-400
|
|
CHARACTERISTIC
|
AUTOMATIC CUTTING BARS&FASCICLE
|
|
APPLICABLE
PLASTIC CLOTH
|
PP/PE
WOVEN BAGS
|
|
PRODUCTION CAPACITY
|
75-90CM(MIN)
|
|
MAXIMUM
OF CUTTING LENGTH
|
1000-8000CM(+.-1.0%)
|
|
MAXIMUM
OF CUTTING WIDTH
|
2100CM
|
|
MAN POWER
|
1PERSONS
|
|
POWER
|
5.5HP
|
|
POWER COMSUMPTION
|
3.6KW
|
| fractionize size |
11mm-210cm |
|
ELECTRIC
HEAT
|
2.6KVA
|
|
MACHINE DIMENSION
|
L4070
x W2650 x H2500MM (N.W 4300KGS)
|
|
THE
SPECIFICATIONS AND SIZES MENTIONED IN THIS LEAFLET ARE SUBJECT TO CHANGE
WITHOUT PRIOR NOTICE
|
Lung - Ye Machinery Co.,Ltd. NO:9Pei Liao Road,Ma Yuan Village,Tzi Tong County,Yunlih Hsien,Taiwan. TEL: +886-5-584-6851 FAX: +886-5-585-0074 http://www.lungye.com.tw E-mail:lye@lungye.com.tw |
